Aluminum foil metal detector
Family: Quality control systems · Catalog p. 12
A conveyor metal detector for products packed in aluminum foil that rejects contaminated packs with an air jet, pusher or flipper.
Technical parameters
- Detector width
- 250 / 350 / 500mm
- Detector height
- 50-120mm
- Sensitivity Fe
- 1.0 / 1.0 / 1.2mm
- Sensitivity SUS 304
- 2.0mm
- Belt width
- 250 / 350 / 500mm
- Conveyor length
- 1200 / 1200 / 1500mm
- Max. weight
- 10 / 15 / 15kg
- Belt height
- 700-820 / 780-900mm
- Rejection
- Air Jet, Pusher, Flipper
Shown as printed in the catalog.
